class: center, middle, inverse, title-slide .title[ # Vectors ] .author[ ### Guilherme Dias ] --- exclude: true count: false <link href="https://fonts.googleapis.com/css?family=Roboto|Source+Sans+Pro:300,400,600|Ubuntu+Mono&subset=latin-ext" rel="stylesheet"> <link rel="stylesheet" href="https://use.fontawesome.com/releases/v5.3.1/css/all.css" integrity="sha384-mzrmE5qonljUremFsqc01SB46JvROS7bZs3IO2EmfFsd15uHvIt+Y8vEf7N7fWAU" crossorigin="anonymous"> <!-- ------------ Only edit title, subtitle & author above this ------------ --> --- name: contents ## Contents - Creating vectors - Calculating with vectors - Indexing: by position, name, condition - Modifying, summarising, counting, sorting - Generating vectors - Factors <img src="images/scooby_vectors.png" width="35%" style="display: block; margin: auto auto auto 0;" /> --- name: atomic_vectors ## Vectors A **vector** holds values of **one type**. Create it with `c()`: ``` r genes <- c("BRCA1", "TP53", "EGFR", "MYC", "GAPDH") expression <- c(5.2, 7.8, 6.1, 9.4, 12.3) length(expression) ``` ``` ## [1] 5 ``` A single value is a vector of length 1. --- name: vec_arithmetic ## Calculating with vectors Operations work on **every element**. Read counts in four samples, normalized to **counts per million (CPM)**: ``` r counts <- c(1520, 830, 2210, 1105) lib_size <- c(20e6, 15e6, 25e6, 18e6) # total reads per sample cpm <- counts / lib_size * 1e6 cpm log2(cpm + 1) ``` ``` ## [1] 76.00000 55.33333 88.40000 61.38889 ## [1] 6.266787 5.815917 6.482203 5.963217 ``` Same length → **element by element**: sample 1 with sample 1, and so on. --- name: recycling_rule ## Recycling Different lengths → the shorter vector is **repeated**: ``` r counts * 2 # 2 is used for every element c(1, 2, 3, 4) + c(0, 100) # c(0, 100) becomes c(0, 100, 0, 100) ``` ``` ## [1] 3040 1660 4420 2210 ## [1] 1 102 3 104 ``` -- Lengths don't fit → **warning**: ``` r c(1, 2, 3, 4, 5) + c(0, 100) ``` ``` ## Warning in c(1, 2, 3, 4, 5) + c(0, 100): longer object length is not a multiple ## of shorter object length ``` ``` ## [1] 1 102 3 104 5 ``` .content-box-yellow[ Recycling one number: useful. Anything else: usually a bug. ] --- name: vec_indexing ## Indexing by position `[ ]` picks elements. R counts from **1**. ``` r genes[2] # second genes[c(1, 3)] # first and third genes[2:4] # second to fourth genes[-5] # all except the fifth genes[10] # beyond the end: NA ``` ``` ## [1] "TP53" ## [1] "BRCA1" "EGFR" ## [1] "TP53" "EGFR" "MYC" ## [1] "BRCA1" "TP53" "EGFR" "MYC" ## [1] NA ``` --- name: vec_indexing_names ## Indexing by name ``` r names(expression) <- genes expression expression["TP53"] expression[c("MYC", "GAPDH")] ``` ``` ## BRCA1 TP53 EGFR MYC GAPDH ## 5.2 7.8 6.1 9.4 12.3 ## TP53 ## 7.8 ## MYC GAPDH ## 9.4 12.3 ``` Names survive reordering. Positions don't. --- name: vec_conditions ## Indexing by condition Keep elements where the condition is `TRUE`: ``` r expression > 7 expression[expression > 7] # values names(expression)[expression > 7] # names which(expression > 7) # positions ``` ``` ## BRCA1 TP53 EGFR MYC GAPDH ## FALSE TRUE FALSE TRUE TRUE ## TP53 MYC GAPDH ## 7.8 9.4 12.3 ## [1] "TP53" "MYC" "GAPDH" ## TP53 MYC GAPDH ## 2 4 5 ``` This is **filtering**. You'll use it all the time. --- name: vec_modify ## Modifying vectors ``` r expr2 <- expression expr2["MYC"] <- NA # failed measurement expr2[expr2 > 10] <- 10 # cap at 10 c(expr2, ACTB = 11.1) # add an element ``` ``` ## BRCA1 TP53 EGFR MYC GAPDH ACTB ## 5.2 7.8 6.1 NA 10.0 11.1 ``` .footnote[Assigning past the end (`x[9] <- 1`) fills the gap with `NA`.] --- name: vec_summaries ## Summarising Ct values of five replicates: ``` r ct <- c(24.1, 25.3, 23.8, 26.0, 24.7) mean(ct) sd(ct) range(ct) ``` ``` ## [1] 24.78 ## [1] 0.8927486 ## [1] 23.8 26.0 ``` -- `NA` is contagious: ``` r ct_missing <- c(24.1, 25.3, NA, 26.0) mean(ct_missing) mean(ct_missing, na.rm = TRUE) ``` ``` ## [1] NA ## [1] 25.13333 ``` --- name: vec_count ## Counting Genotypes of 10 individuals at one SNP: ``` r genotype <- c("AA", "AG", "GG", "AG", "AA", "AG", "AA", "AA", "GG", "AG") unique(genotype) table(genotype) table(genotype) / length(genotype) # frequencies ``` ``` ## [1] "AA" "AG" "GG" ## genotype ## AA AG GG ## 4 4 2 ## genotype ## AA AG GG ## 0.4 0.4 0.2 ``` --- name: vec_sorting ## Sorting ``` r sort(expression) # lowest first sort(expression, decreasing = TRUE) # highest first ``` ``` ## BRCA1 EGFR TP53 MYC GAPDH ## 5.2 6.1 7.8 9.4 12.3 ## GAPDH MYC TP53 EGFR BRCA1 ## 12.3 9.4 7.8 6.1 5.2 ``` -- `order()` gives positions. Use it to sort one vector by another: ``` r genes[order(expression, decreasing = TRUE)] # genes ranked by expression ``` ``` ## [1] "GAPDH" "MYC" "TP53" "EGFR" "BRCA1" ``` .footnote[`sort()` drops `NA`s.] --- name: seq ## Generating vectors ``` r 1:6 seq(from = 0, to = 24, by = 6) # time points (hours) rep(c("control", "treated"), each = 3) # group labels paste0("S", 1:6) # sample names paste(genes, collapse = ", ") # many strings → one ``` ``` ## [1] 1 2 3 4 5 6 ## [1] 0 6 12 18 24 ## [1] "control" "control" "control" "treated" "treated" "treated" ## [1] "S1" "S2" "S3" "S4" "S5" "S6" ## [1] "BRCA1, TP53, EGFR, MYC, GAPDH" ``` --- name: random_sample ## Random sampling Randomly assign six mice to groups: ``` r mice <- paste0("M", 1:6) set.seed(42) # same random result every time sample(mice) # first 3 treated, last 3 control ``` ``` ## [1] "M1" "M5" "M6" "M4" "M2" "M3" ``` -- With replacement: ``` r sample(c("AA", "AG", "GG"), size = 10, replace = TRUE) ``` ``` ## [1] "AG" "AG" "AA" "GG" "GG" "AA" "AA" "AG" "AG" "AG" ``` --- name: factors ## Factors Categories, such as groups. Possible values = **levels**. ``` r strain <- factor(c("WT", "KO", "WT", "KO", "KO", "WT")) levels(strain) # alphabetical: KO first table(strain) ``` ``` ## [1] "KO" "WT" ## strain ## KO WT ## 3 3 ``` -- The first level is the **reference** (plots, models). Set it yourself: ``` r strain <- factor(strain, levels = c("WT", "KO")) levels(strain) ``` ``` ## [1] "WT" "KO" ``` --- name: ordered_fac ## Ordered factors For categories with a natural order: ``` r severity <- c("mild", "severe", "moderate", "mild", "severe") severity <- factor(severity, levels = c("mild", "moderate", "severe"), ordered = TRUE) severity severity > "mild" ``` ``` ## [1] mild severe moderate mild severe ## Levels: mild < moderate < severe ## [1] FALSE TRUE TRUE FALSE TRUE ``` --- name: recap ## Recap | Task | Example | |:-----|:--------| | Create | `c(5.2, 7.8, 6.1)` | | Calculate | `counts / lib_size * 1e6` | | Index | `x[2]`, `x["TP53"]`, `x[x > 7]` | | Modify | `x["MYC"] <- NA` | | Summarise | `mean(x, na.rm = TRUE)`, `table(x)` | | Sort | `sort(x)`, `genes[order(x)]` | | Generate | `seq()`, `rep()`, `paste0()`, `sample()` | | Categories | `factor(x, levels = ...)` | <br> **Remember:** one type per vector. Element by element. Short vectors get recycled. <!-- --------------------- Do not edit this and below --------------------- --> --- name: end_slide class: end-slide, middle count: false # We will talk about matrices in the next lecture! .end-text[ <p class="smaller"> <span class="small" style="line-height: 1.2;">Graphics from </span><img src="./assets/freepik.jpg" style="max-height:20px; vertical-align:middle;"><br> Created: 12-Nov-2026 • <a href="https://www.scilifelab.se/">SciLifeLab</a> • <a href="https://nbis.se/">NBIS</a> </p> ]
